22mm 10 x 60° Optical Led Lens , LED Wall Washer Light Landscape Lighting Kits

Good quality 3030 LED Lens for sales
Good quality 3030 LED Lens for sales
These optics lenses fit my LED's perfectly, and do their job well. Really extends the light !

—— Keith Taylor

Works as expected with star pcb LEDs. Bought for brightness comparison testing for some custom lighting. Quality lens and housing !

—— Tim Stinson

Works great to focus the LED beam down to a manageable point. Used these for the lenses to shoot the led light up the blade for lightsabers.

—— Petru Dinga

Lens work well, and price is good. Especially impressed with your good service. Your smile is very sweet !

—— Walton Ussery

I'm Online Chat Now

22mm 10 x 60° Optical Led Lens , LED Wall Washer Light Landscape Lighting Kits

China 22mm 10 x 60° Optical Led Lens , LED Wall Washer Light Landscape Lighting Kits supplier
22mm 10 x 60° Optical Led Lens , LED Wall Washer Light Landscape Lighting Kits supplier 22mm 10 x 60° Optical Led Lens , LED Wall Washer Light Landscape Lighting Kits supplier 22mm 10 x 60° Optical Led Lens , LED Wall Washer Light Landscape Lighting Kits supplier

Large Image :  22mm 10 x 60° Optical Led Lens , LED Wall Washer Light Landscape Lighting Kits

Product Details:

Place of Origin: Shenzhen, Guangdong
Brand Name: HIKE
Certification: SGS, ROHS
Model Number: HK-2212-1060D

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: 100pcs in one carton box, carton size is 57cm*29cm*29cm.
Delivery Time: 2-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 4000000 Pieces/ per month
Contact Now
Detailed Product Description
Material:: PMMA Diameter:: 22mm
Beam Angle:: 15° 30° 45° 60° 10 X 60° 10 X 70° 20 X 40° 10 X 35° Height:: 12mm
Working Temperature:: -35°-90° Suitable Led:: XPE / XBD / OSRAM 3030 / 2835
Application:: LED Wall Washer Light Sample:: For Free



22mm 10 x 60° Optical Led Lens , LED Wall Washer Light Landscape Lighting Kits



  • Full Width Half Maxium. A measurement between two data points on either side of the peak, where the light intensity is 50-percent of the maximum value.
  • When talking about lens optics the larger the optic the easier it is to collimate light into a tighter pattern. Another consideration when trying to achieve a tight spot is the size of the LED die. The smaller the size of the die the tighter the spot.
  • When we think of an LED optic, we tend to think of a clear plastic lens that is placed on top of the LED itself to focus or spread the light. If this is your thought process, you’ve gone too far.
  • Lets take a step back and look at the LED itself. See that small protective dome over the diode? That is actually called the primary optic which serves to protect and shape the output of the small diode.
  • The light from the LEDs primary optic is still too broad for most applications, lacking intensity over distance. This is why most LED fixtures use secondary optics (lenses, reflectors, TIR optics, etc.) to collect all that light and magnify its intensity towards the target.



Product Description:



Lens' Model Number HK-2212-1060D
Diameter 22mm
Beam Angel 15° 30° 45° 60° 10 x 60° 10 x 70° 20 x 40° 10 x 35°
Material PMMA
Temperature -35℃-90℃
Height 12mm
LED series XPE / XBD / OSRAM 3030 / 2835





Drawing:



22mm 10 x 60° Optical Led Lens , LED Wall Washer Light Landscape Lighting Kits





Our Service:



1. Your inquiry will be replied by professional sales in 8 hours.



2. OEM & ODM are welcomed, OEM brand is available.



3. Distributorship is offered for your unique design and some our current models.



4. Protection of your sales area, ideas of design and all your private information.



5. 2 years' warranty.



6. Provide you the lowest freight cost and the best service.



7. Professional engineers to design and develop new led street light components according to your requirements.



8. When you have larger quantity, we can design the color boxes for you, and use your logo and label on the products if u need.





Application:



22mm 10 x 60° Optical Led Lens , LED Wall Washer Light Landscape Lighting Kits
